Automatic vertical convection thermal system
Designed for coating processes, post-dispensing backend processes, and intended to address operational needs.
SOLUTIONS
Save energy and floor space
Unique concept
CONFIGURATION FLEXIBILITY
- Photoelectric sensor.
- Lifting.
- Perfect width adjustment mechanism.
- Fiber optic sensor.
- Dual lane option.
PRODUCTIVITY
- Improving temperature uniformity.
- Unique horizontal + up & down air.
- Embedded trend analysis.
- High thermal efficiency and uniformity.
- Heating layers: up to 65.
- Dual lane option.
- 130 positions.
TRACEABILITY (SMARTBOX OPTION)
- Process tracker.
- Live process parameters log.
- Embedded trend analysis.
OPTIMIZATION
- Floor space & facility savings.
- Energy efficient.
Features
- PCB size: 600×500 mm (LxW).
- Conveyor: Bottom and return.
- Distance between slots: Adjustable: ex. 25 mm (64 layers) – 75 mm (16 layers).
- Numbers of slots: front 32 cages, rear 32 cages.
- Weight: More than 5 kg per layer.
- Heating control: PID closed-loop control + high-frequency pulse.
- Photoelectric sensor: Detects the PCB position.
- Fiber optic sensor: Detects the PCB position.
- Lifting limit: Fiber detection.
- Width-adjusting device: The movable rail is used to adjust the width.
- Safety: CE-compliant safety measures and protection devices.
Application
Preheat and cure of underfill, potting, glue, corner bonding, thermal paste, gap filler, coating, ink, etc.
