Multi-purpose vision engine for ultra-high speed inspection and on-demand image analysis
Super-fast 2D inspection and image analysis with advanced capabilities for coating, dispensing, component insertion, THT, and wave soldering process lines.
SOLUTIONS
Vision system for integration into a process line.
High speed 2D AOI / ACI with film thickness measurement capability.
OUR TECHNOLOGY
Unique Concept.
CONFIGURATION FLEXIBILITY
- Automated AI-based vision engine with pre-configured functionalities for quality inspection in coating, dispensing, THT, and wave soldering processes.
- Dimensions: PCBA-pallets: up to 710×540 mm. Max. pallet weight: 20 kg.
- 150 mm Top/Bottom clearance.
- FOV size up to 500×450 mm (710×540 mm FOV optional).
- Multi-language 32’’ intuitive HMI.
- No air supply required.
PRODUCTIVITY
- 4 seconds cycle time.
- Traceability reading while inspection.
FULL INTERCONNECTED TRACEABILITY (
OPTION)
- Process Tracker embedded software platform with on demand communication & KPI definition.
- Live process parameters log.
- Embedded trend analysis.
OPTIMIZATION
- Floor space & Energy efficient.
- Eco-friendly.
Options
- Coating thickness trend measurement IPC compliant.
- User friendly repair station.
- Review station.
Process monitoring options
- Offline programming.
- Remote control platform.
- Coating film thickness.
Thanks to our technology, all recorded data can be shared with an MES/FIS environment and displayed through our embedded Process Tracker, providing enhanced process capability visibility via a local KPI display system.
- OK/NOK post inspection management.
- Advance resolution (18 µm).
- Extended size FOV up to 800 x 500 mm.
Application
- AOI (Automatic Optical Inspection) Dispensing, potting, glue, gap filler, underfill, screw, top THT, wax, foreign particles, 1D/2D codes and more.
- ACI (Automatic Coating Inspection) Coating, nano coating and silicone.
Features
- Resolution standard down to 50 um.
- Standard FOV up to 500 x 450 mm.
- Intuitive programming UI.
- inspection time less than 4 sec.
- Ultra-thin coating compatible.
- Light source: multi-LED illumination.
- No periodical calibration of camera needs.
